Molex 1731091391 — D-Sub Cable Assemblies

Molex 1731091391 D-Sub Plug, 25-Pin, DB-25, Solder Cup

MPN1731091391
Active

Molex F, FCT 173109 series D-Sub plug, 25 positions, 2 rows, DB-25 shell size, 5 A, through-hole solder termination, machined copper alloy contacts.

$11.6700Ref. price · indicative, final on quote
Molex 1731091391 datasheet (PDF)
SeriesF, FCT 173109
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1731091391 key specifications
ParameterValue
SeriesF, FCT 173109
TypeSignal
MountingThrough Hole
Connector typePlug, Male Pins
Current rating5A
Contact formMachined
Shell size, connector layout3 (DB, B)
Operating temperature-55°C ~ 125°C
ColorWhite
Contact materialCopper Alloy
Primary materialMetal
Dielectric materialPolyester, Glass Filled

All specifications

1731091391 additional specifications
ParameterValue
Shell material, finishSteel, Tin Plated
Material flammability ratingUL94 V-0
PackageBulk
FeaturesGrounding Indents
TerminationSolder
Flange featureHousing/Shell (Unthreaded)
Rows2
Positions25

Product details

DB-25 Plug, 25 Male Pins, Solder Termination

The Molex 1731091391 is a 25-position D-Sub plug (male pin) from the F, FCT 173109 series, built in the standard DB-25 shell size — layout 3 (DB, B). It carries 25 machined copper alloy signal contacts rated 5 A each, terminated via solder cups for through-hole mounting.

25 Positions, DB-25 Shell, 5 A Signal Duty

The unthreaded housing/shell flange accepts standard D-sub hardware (slide locks or screw-locks, not included). Termination is solder cup — the machined pins accept 20-28 AWG stranded wire for hand or wave soldering. The through-hole mounting legs stabilise the connector during soldering and provide mechanical retention to the PCB.

Frequently asked questions

Is 1731091391 compatible with standard D-sub backshells?

Yes — the DB-25 shell size and unthreaded flange are standard for D-sub backshells. Any backshell designed for a DB-25 male connector with solder-cup contacts will fit, provided it accommodates the through-hole mounting legs.
