2016060610 — Molex product photo
Molex

Molex 2016060610 Universal Clamp Terminal Block, 600 V

MPN2016060610
Active

Molex 201606 series Universal Clamp terminal block, 1 position, 600 V, 1/0-8 AWG, screw termination, DIN rail mount, gray housing.

$10.0700Ref. price · indicative, final on quote
2016060610 datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

2016060610 Technical Specifications
ParameterValue
TypeUniversal Clamp
Series201606
Mounting typeDIN Rail
Voltage - UL600 V
Terminal - width17.8mm
Wire gauge or range - AWG1/0-8 AWG
Wire gauge or range - mm28.3-53mm²
Operating temperature-40°C ~ 125°C
Height1.693\" (43.00mm)
Housing colorGray
Material - insulationPolyamide (PA), Nylon
Length1.929\" (49.00mm)
PackageBulk
ManufacturerMolex
Number of levels1
Termination styleScrew
Positions1

Product details

What the Molex 2016060610 Universal Clamp Is

The Molex 2016060610 is a single-position Universal Clamp terminal block from the 201606 series, designed for DIN rail mounting. It accepts heavy cable from 1/0 to 8 AWG (8.3-53 mm²) via a screw termination — the clamp grips the full conductor cross-section without damaging strands. Rated 600 V UL, it handles the main power feed in a control cabinet or distribution panel, not signal-level wiring.

Key Specs for the Panel Builder

The single-level design keeps wiring tidy: one conductor in, one out, with the screw clamp holding the wire against the current bar. Overall dimensions: 1.929" (49.00 mm) long, 1.693" (43.00 mm) tall, 17.8 mm wide — the width is the DIN rail footprint, so it takes up one standard 17.8 mm module on the rail.

Frequently asked questions

Is the Molex 2016060610 DIN rail mountable?

Yes, the 2016060610 mounts directly onto a standard DIN rail — the housing clips onto the rail without tools, and the screw termination is accessible from the front.
