Molex 2068321201 — Pin Headers

Molex 2068321201 Micro-Fit+ Header 12 Pos 3mm

MPN2068321201
Active

Molex Micro-Fit+ 206832 series, Board to Cable/Wire, 12-position, dual-row, shrouded header, 3.00mm pitch, through-hole solder, locking ramp, 12.5A per contact, 600VAC/DC, -40°C to 105°C, UL94 V-0, glow wire compliant.

$2.3700Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesMicro-Fit+ 206832
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

2068321201 key specifications
ParameterValue
SeriesMicro-Fit+ 206832
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLocking Ramp
Voltage rating600VAC/DC
Current rating12.5A per Contact
Operating temperature-40°C ~ 105°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.390\" (9.91mm)
Insulation materialLiquid Crystal Polymer (LCP), Glass Filled

All specifications

2068321201 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageTray
FeaturesBoard Guide, Glow Wire Compliant
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Medical, Telecommunications
Contact shapeSquare
Rows2
Pitch0.118\" (3.00mm)
Positions12
Row spacing - mating0.118\" (3.00mm)
Contact finish - postTin
Contact length - post0.125\" (3.18mm)
Contact finish - matingTin

Product details

The 2068321201: The current rating is not a signal-level spec; it drives the choice of mating terminal and wire gauge. For a 12-position dual-row header, the total power path through the connector can exceed 150 A if evenly distributed, but the practical limit is set by the harness-side crimp terminals and the temperature rise inside the housing.

Locking ramp and glow wire — where this header fits

The glow wire compliant feature (likely IEC 60335-1) makes it suitable for household appliances where the connector must not sustain a flame after a fault.

Frequently asked questions

What is the mating connector for Molex 2068321201?

The mating half is a Micro-Fit+ receptacle housing, typically from the Molex 43025 series, with the corresponding female crimp terminals.

What terminals are compatible with 2068321201?

Standard Micro-Fit+ female crimp terminals rated for 12.5 A, typically Molex 43030 or 43031 series, depending on wire gauge. Confirm the terminal part number with the receptacle housing.
