Molex 482580001 USB 2.0 Type-A Receptacle, 4 Pos, 1.5 A

MPN482580001
Active

Molex 48258 series USB 2.0 Type-A receptacle, 4 contacts, right-angle through-hole, shielded, gold-plated contacts, 1.5 A, 250 VAC, UL94 V-0.

$1.45Ref. price · indicative, final on quote
482580001 datasheet
StockIn Stock (18)
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

482580001 Technical Specifications
ParameterValue
Series48258
Mounting typeBoard Edge, Cutout; Through Hole, Right Angle
Connector typeUSB-A (USB TYPE-A)
Voltage - rated250VAC
Current rating1.5A
Positions4
Mounting featureHorizontal, Mid Mount
Operating temperature-25°C ~ 85°C
Insulation colorBlack
Shell (Shielding material)Brass
Material flammability ratingUL94 V-0
GenderReceptacle
PackageTape & Reel (TR); Cut Tape (CT)
FeaturesBoard Lock, Solder Retention
ShieldingShielded
TerminationSolder
Contact finishGold
SpecificationsUSB 2.0
Number of ports1

Product details

USB 2.0 Type-A Receptacle for Board-Edge Mounting

The Molex 482580001 is a USB 2.0 Type-A receptacle from the 48258 series, offering 4 contacts in a single port. The shielded brass shell and gold-plated contacts support the USB 2.0 signal standard, rated at 1.5 A per contact and 250 VAC.

This receptacle uses board-edge, right-angle through-hole solder termination.

Current and Voltage Rating

Rated at 1.5 A per contact and 250 VAC, the 482580001 covers the USB 2.0 power envelope (500 mA standard) with margin for low-power charging. The 1.5 A limit is a per-contact figure — the total current through the receptacle depends on the PCB trace width and ambient temperature, but the connector itself is not the bottleneck for typical USB 2.0 duty. The 250 VAC rating is a dielectric withstand spec, not a working voltage for the signal pair; the USB 2.0 differential pair operates at 3.3 V logic levels.

Shielding and Compliance

The shielded brass shell provides EMI containment for the USB 2.0 signal pair, which is essential for passing radiated emissions testing in commercial equipment.

Frequently asked questions

What is the mounting type of 482580001?

The 482580001 is a right-angle, through-hole receptacle designed for board-edge mounting with a horizontal mid-mount orientation.
