The 5017865091: It accepts a 0.30 mm-thick notched FFC and terminates via solder to the board.
Board-fit and retention details
The slide lock secures the FFC after insertion — no secondary latch needed.
Molex 5017865091 FFC Connector 0.5mm 50 Pos Vertical SMD
MPN5017865091
Active
Molex Easy-On 501786 series, FFC connector, 0.020" (0.50mm) pitch, 50 positions, vertical SMD, gold-plated phosphor bronze contacts, 0.5 A per contact, 50 V rating.
$4.2100Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesEasy-On 501786
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — typically 7–15 days door-to-door
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Easy-On 501786 |
| Mounting | Surface Mount |
| Cable end type | Notched |
| Flat flex type | FFC |
| Connector (Contact type) | Contacts, Vertical - 1 Sided |
| Voltage rating | 50V |
| Current rating | 0.5A |
| Operating temperature | -40°C ~ 85°C |
| Housing color | Black |
| Contact material | Phosphor Bronze |
| Housing material | Liquid Crystal Polymer (LCP), Glass Filled |
| Height above board | 0.234\" (5.95mm) |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Pitch | 0.020\" (0.50mm) |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Board Guide, Solder Retention |
| Termination | Solder |
| Mating cycles | 20 |
| Contact finish | Gold |
| Locking feature | Slide Lock |
| FFC, FCB thickness | 0.30mm |
| Positions | 50 |
| Contact finish thickness | 39.4µin (1.00µm) |
Product details
Frequently asked questions
Is 5017865091 RoHS compliant?
Yes, ROHS3 compliant.
What is the pitch of Molex 5017865091?
0.020" (0.50mm) pitch, 50 positions.
