Molex 5019203001

5019203001 Molex SlimStack Plug 30 Pos 0.50mm Pitch

MPN 5019203001
Active

Molex SlimStack 501920 series, 30-position plug, 0.020" (0.50mm) pitch, dual-row, gold-plated outer shroud contacts, surface-mount, 4mm mated stacking height, Tape & Reel.

$3.6000 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesSlimStack 501920
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

5019203001 specifications
ParameterValue
SeriesSlimStack 501920
MountingSurface Mount
Connector typePlug, Outer Shroud Contacts
Height above board0.135\" (3.43mm)
Mated stacking heights4mm
Pitch0.020\" (0.50mm)
PackageTape & Reel (TR) Cut Tape (CT)
Contact finishGold
Rows2
Positions30

Product details

Pitch-first board fit for a 4 mm gap

The 5019203001: That pitch forces a fine-line PCB fan-out — expect 0.25 mm trace/space minimum on the inner layers — but it's the only way to hit a 4 mm mated stack height from a 3.43 mm plug body. The outer shroud contacts mean this is the male member: the receptacle (mating half) has inner contacts that nest inside the shroud.

Stack-height budget and the mating half

The mated stacking height is 4 mm — the sum of this plug's 3.43 mm above-board height plus the receptacle's own height. To hit that 4 mm total, the mating receptacle (Molex SlimStack 501920 series, 30-position receptacle) must be selected with the same pitch and row count. The plug's surface-mount termination and Tape & Reel packaging suit automated pick-and-place for high-volume board assembly.
