Molex Pico-Lock 504050 series, 5040500491, 4-circuit single-row header, 1.50 mm pitch, surface-mount right-angle, shrouded 4-wall, gold-plated male blade contacts, detent lock, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Pico-Lock 504050 |
| Type | Male Blade |
| Mounting | Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Detent Lock |
| Voltage rating | 150V |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.079\" (2.00mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial, Lighting, Telecommunications |
| Contact shape | Rectangular |
| Rows | 1 |
| Pitch | 0.059\" (1.50mm) |
| Positions | 4 |
| Contact finish - post | Gold |
| Contact finish - mating | Gold |
| Contact finish thickness - mating | 3.94µin (0.100µm) |
The 5040500491: This is a Molex Pico-Lock 504050 series single-row header with 4 circuits on a 1.50 mm pitch, terminated by SMT solder to the board. The right-angle orientation routes the mating cable parallel to the PCB surface, saving vertical clearance in compact enclosures. The 4-wall shrouding protects the male blade contacts during handling and guides the mating receptacle into alignment.
We source the 5040500491 to order against your BOM line. Submit an RFQ with your target quantity and we will return current pricing and lead time. No stock-holding claim — confirmed at quote time.
The mating pitch is 0.059" (1.50 mm). This is a single-row, 4-position header.
Yes, it is ROHS3 compliant.
