Molex BackFlip, Easy-On LA75 504754 FPC connector, 9 positions, 0.30 mm pitch, right-angle SMT, Flip Lock backlock, gold-plated contacts, 0.2 A, 50 V, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | BackFlip, Easy-On LA75 504754 |
| Mounting | Surface Mount, Right Angle |
| Cable end type | Tabbed |
| Flat flex type | FPC |
| Connector (Contact type) | Contacts, Top and Bottom |
| Voltage rating | 50V |
| Current rating | 0.2A |
| Operating temperature | -40°C ~ 85°C |
| Housing color | Black |
| Actuator color | Gray |
| Contact material | Copper Alloy |
| Housing material | Liquid Crystal Polymer (LCP), Glass Filled |
| Parameter | Value |
|---|---|
| Actuator material | Polyamide (PA), Nylon, Glass Filled |
| Height above board | 0.030\" (0.75mm) |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.012\" (0.30mm) |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Termination | Solder |
| Mating cycles | 10 |
| Contact finish | Gold |
| Locking feature | Flip Lock, Backlock |
| FFC, FCB thickness | 0.20mm |
| Positions | 9 |
| Contact finish thickness | 3.94µin (0.10µm) |
Molex 5047540900 is a 9-position FPC connector from the BackFlip, Easy-On LA75 504754 series, with a 0.30 mm pitch and right-angle SMT orientation. The Flip Lock and Backlock feature secures the FPC against pull-out during handling and moderate vibration.
No, the 5047540900 is listed as Active with no end-of-life notice. It remains available for BOM replenishment.
The pitch is 0.30 mm (0.012"). This is the tightest pitch in the LA75 series, driving a compact board footprint.
Yes, it uses a Flip Lock, Backlock mechanism to secure the FPC against pull-out during handling and moderate vibration.
