5051100697 — Molex product photo
Molex

Molex 5051100697 Easy-On FD19 FFC Connector, 6 Pos

MPN5051100697
Active

Molex Easy-On FD19 505110, 6-position FFC/FPC connector, 0.020" (0.50mm) pitch, right-angle SMT, ZIF flip-lock, bottom contact, gold flash, 0.5A, 50V, -40°C to 150°C.

$0.7100Ref. price · indicative, final on quote
5051100697 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

5051100697 Technical Specifications
ParameterValue
SeriesEasy-On FD19 505110
Mounting typeSurface Mount, Right Angle
Cable end typeStraight, Tabbed
Flat flex typeFFC, FPC
Connector (Contact type)Contacts, Bottom
Voltage rating50V
Current rating0.5A
Operating temperature-40°C ~ 150°C
Housing colorBeige
Actuator colorBlack
Contact materialCopper Alloy
Housing materialLiquid Crystal Polymer (LCP), Glass Filled
Actuator materialPolyamide (PA), Nylon, Glass Filled
Height above board0.075\" (1.90mm)
Material flammability ratingUL94 V-0
Pitch0.020\" (0.50mm)
PackageTape & Reel (TR) Cut Tape (CT)
FeaturesSolder Retention, Zero Insertion Force (ZIF)
TerminationSolder
Mating cycles20
Contact finishGold
Locking featureFlip Lock
FFC, FCB thickness0.30mm
Positions6
Contact finish thickness2.00µin (0.051µm)

Product details

0.50mm pitch, 6-position ZIF for tight board-edge routing

The 5051100697: The 0.50mm pitch on this 6-position FFC connector sets the PCB footprint and the routing density for the FPC traces — the narrow spacing limits per-contact current to 0.5A, which is the thermal ceiling for the contact beam and housing at the rated temperature. Zero insertion force actuation with a flip-lock: the actuator lifts to accept the FPC without scraping the pads, then locks down to hold the 0.30mm-thick cable.

20 mating cycles and gold flash — reconnect duty is limited

The 2.00µin gold flash on the contact surface protects against corrosion during the rated life but does not support the hundreds of cycles a heavier gold plating would.

Active production, ROHS3, sourced per RFQ

No pin-compatible direct replacement listed from Molex for this exact order code within the Easy-On FD19 series. Confirm the mating FPC thickness (0.30mm) and the bottom-contact orientation before committing the BOM line.

Frequently asked questions

What is the pitch of Molex 5051100697?

The pitch is 0.020" (0.50mm). This sets the PCB footprint and the minimum trace/space for the FPC routing.

What is the mating cycle life of 5051100697?

Rated for 20 mating cycles. This is a low-cycle connector — suitable for infrequent disconnect during assembly or service, not for repeated field reconnection.

Does 5051100697 have a locking feature?

Yes, it has a flip-lock actuator that provides zero insertion force (ZIF) actuation and holds the FPC in place without a secondary latch.

Where can I buy 5051100697?

Sourced to order against the BOM quantity through independent distribution.
