Molex Easy-On FS19 505278, 15-position, 0.50 mm pitch, right-angle SMT, 0.5 A, flip lock, tin contacts, beige housing, ROHS3 compliant
| Parameter | Value |
|---|---|
| Series | Easy-On FS19 505278 |
| Mounting | Surface Mount, Right Angle |
| Cable end type | Tabbed, Tapered |
| Flat flex type | FFC, FPC |
| Connector (Contact type) | Contacts, Bottom |
| Voltage rating | 50V |
| Current rating | 0.5A |
| Operating temperature | -40°C ~ 85°C |
| Housing color | Beige |
| Actuator color | Black |
| Contact material | Phosphor Bronze |
| Housing material | Liquid Crystal Polymer (LCP), Glass Filled |
| Parameter | Value |
|---|---|
| Actuator material | Polyamide (PA), Nylon, Glass Filled |
| Height above board | 0.075\" (1.90mm) |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.020\" (0.50mm) |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Solder Retention |
| Termination | Solder |
| Mating cycles | 25 |
| Contact finish | Tin |
| Locking feature | Flip Lock |
| FFC, FCB thickness | 0.30mm |
| Positions | 15 |
| Contact finish thickness | 39.4µin (1.00µm) |
The Molex 5052781533 is a 15-position, 0.50 mm pitch FFC/FPC connector from the Easy-On FS19 505278 series. The flip lock secures a 0.30 mm thick FFC without extra hardware.
The tin contact finish (39.4 µin) handles 25 mating cycles, enough for production and one field service event.
The 5052781533 is an active Molex part. We source it per RFQ — send a BOM quantity for current pricing and availability.
0.50 mm pitch, 15 positions. The right-angle SMT footprint matches standard 0.50 mm FFC layouts.
