Receptacle Housing for a 10-Circuit CP-3.3 Harness
The Molex 5056051001 is a 10-position, dual-row receptacle housing from the CP-3.3 series, pitched at 3.30 mm.
The 3.30 mm pitch is wider than the common 2.54 mm or 3.00 mm standards, which means the mating header and the board footprint must match this exact spacing — a 3.00 mm header will not align. The dual-row, 10-position layout gives five positions per row, a configuration that balances wire bundle density against the housing width for a 10-circuit harness.
Latch Holder and Polarization
The housing is polarized through its keying geometry — it will only mate in one orientation, which eliminates miswiring on the line.
