Molex 5056061001 — Connector Housings

Molex CP-3.3 5056061001 Plug Housing, 10 Pos, 3.30mm

MPN5056061001
Active

Molex CP-3.3 505606 series, plug housing, 10 positions, 2 rows, 0.130" (3.30mm) pitch, crimp termination, latch lock, free hanging, black PBT, -40°C to 105°C.

$0.6900Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesCP-3.3 505606
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

5056061001 specifications
ParameterValue
SeriesCP-3.3 505606
TypeMale Pin
MountingFree Hanging (In-Line)
Connector typePlug
Fastening typeLatch Lock
Operating temperature-40°C ~ 105°C
ColorBlack
Insulation materialPolybutylene Terephthalate (PBT), Polyester
NoteContacts Not Included
Pitch0.130\" (3.30mm)
PackageBulk
Rows2
Contact terminationCrimp
Positions10

Product details

The Molex 5056061001 is a 10-circuit plug housing from the CP-3.3 505606 series, a 3.30 mm pitch wire-to-wire interconnect family. It is the free-hanging (in-line) half of a two-piece connector system — the receptacle mates with a matching header.

You need to source the male pin crimp terminals separately — the CP-3.3 series uses a specific terminal (often Molex 505606-... or equivalent) that matches the 3.30 mm pitch and the housing cavity. Buying the housing alone and forgetting the terminals is the single most common BOM miss on this part.

This plug housing accepts male pin contacts via crimp termination. The mating half is a CP-3.3 receptacle header with the same 3.30 mm pitch and 10 circuits — look for the 505606 series receptacle housings. The latch lock engages audibly when fully mated; no secondary lock is listed, so verify terminal retention by feel during assembly.

Frequently asked questions

Does 5056061001 include contacts?

No, contacts are not included with this housing. You must order the male pin crimp terminals separately.

What is the pitch of Molex 5056061001?

The pitch is 0.130" (3.30 mm).

What terminals work with 5056061001 housing?

The housing accepts male pin crimp terminals from the CP-3.3 series. The specific terminal part number is not listed here — confirm it matches the 3.30 mm pitch and your wire gauge.
