Molex 67329 series USB-A (Type-A) receptacle, 4 contacts, USB 2.0, right-angle through-hole, shielded, gold-plated contacts, 1A rating, UL94 V-0, board lock.
| Parameter | Value |
|---|---|
| Series | 67329 |
| Mounting type | Through Hole, Right Angle |
| Connector type | USB-A (USB TYPE-A) |
| Current rating | 1A |
| Positions | 4 |
| Mounting feature | Vertical |
| Insulation color | Black |
| Shell (Shielding material) | Copper Alloy |
| Material flammability rating | UL94 V-0 |
| Gender | Receptacle |
| Package | Tray |
| Features | Board Lock |
| Shielding | Shielded |
| Termination | Solder |
| Contact finish | Gold |
| Specifications | USB 2.0 |
| Number of ports | 1 |
The Molex 673298000 is a USB-A (Type-A) receptacle from the 67329 series, configured with 4 contacts and rated for USB 2.0 signaling.
The 1 A per-contact rating is standard for USB 2.0 power delivery — enough to charge a peripheral or power a low-current device, but not for high-power USB-C or PD applications.
Submit a request for current pricing and availability; lead time and stock are confirmed at quote time.
As a standard USB-A receptacle, the 4 contacts follow the USB 2.0 pinout: VBUS, D-, D+, and GND.
