Pulse Electronics — Modular / RJ Connectors

Pulse Electronics Modular / RJ Connectors — 25 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Height Above Board
0.545" (13.84mm) · 0.445" (11.30mm) · 0.550" (13.97mm) · 0.536" (13.61mm)
LED Color
Does Not Contain LED · Green, Yellow - Green · Yellow - Green · Green - Yellow
Housing Material
Polyamide (PA10T), Nylon 10T · Polybutylene Terephthalate (PBT), Glass Filled · Polyamide (PA), Nylon, Glass Filled · Polyester, Glass Filled
Applications
10/100 Base-TX, AutoMDIX · 10/100 Base-TX · 10/100/1000 Base-T, AutoMDIX · 10/100/1000 Base-T, AutoMDIX, Power over Ethernet+ (PoE+)
Contact Finish Thickness
30.0µin (0.76µm) · 3.00µin (0.076µm) · 6.00µin (0.152µm) · 15.0µin (0.38µm)
Package
Tape & Reel (TR) Cut Tape (CT) · Bulk · Tray · Tube
Tab Direction
User Selectable · Down · Up and Down · Up
Contact Material
Phosphor Bronze · Copper Alloy · Brass
