Qualtek 701W series IEC 320-C14 power entry receptacle, order code 701W-X2/02, 3 positions, 10 A at 250 VAC, panel mount snap-in, solder eyelet termination, unfiltered commercial grade.
| Parameter | Value |
|---|---|
| Series | 701W |
| Filter type | Unfiltered - Commercial |
| Mounting | Panel Mount, Snap-In |
| Connector type | IEC 320-C14 |
| Voltage rating - appliance inlet | 250VAC |
| Current rating - appliance inlet | 10A |
| Panel cutout | Rectangular - 27.00mm x 20.00mm |
| Approval agency | CCC, CSA, UL, VDE |
| Package | Bulk |
| Termination | Solder Eyelet |
| Panel thickness | 0.032\" ~ 0.059\" (0.81mm ~ 1.50mm) |
| Accomodates a fuse | No |
| Positions | 3 |
The 701W-X2/02 is the 3-position IEC 320-C14 receptacle in Qualtek's 701W power entry module line, rated 10 A at 250 VAC. Mounts via panel snap-in into a rectangular 27.00 mm x 20.00 mm cutout; termination is solder eyelet for wire leads. Unfiltered commercial grade — no integrated fuse holder — with approvals from CCC, CSA, UL, and VDE.
The part carries ROHS3 compliance and approvals from CCC, CSA, UL, and VDE.
A rectangular cutout measuring 27.00 mm x 20.00 mm, with panel thickness from 0.032" to 0.059" (0.81 mm to 1.50 mm).
No. This inlet does not accommodate a fuse — it is an unfiltered commercial grade receptacle.
