710W series IEC 320-2-2/F receptacle, order code 710W-00/02, 3 positions, 10 A at 250 VAC, unfiltered commercial, panel mount flange, quick connect 0.189" (4.8 mm) termination, female sockets.
| Parameter | Value |
|---|---|
| Series | 710W |
| Filter type | Unfiltered - Commercial |
| Mounting | Panel Mount, Flange |
| Connector type | IEC 320-2-2/F |
| Voltage rating - appliance inlet | 250VAC |
| Current rating - appliance inlet | 10A |
| Panel cutout | Rectangular - 32.50mm x 25.00mm |
| Approval agency | CSA, TUV, UL |
| Package | Bulk |
| Termination | Quick Connect - 0.189\" (4.8mm) |
| Accomodates a fuse | No |
| Positions | 3 |
The 710W-00/02 is a 3-position IEC 320-2-2/F receptacle in the 710W series, rated 10 A at 250 VAC with quick-connect 0.189" (4.8 mm) termination. Mounts via a panel flange into a rectangular cutout 32.50 mm x 25.00 mm; the unfiltered commercial variant carries no integrated fuse or EMI suppression.
