Qualtek 716W series IEC 320-2-2/F receptacle, order code 716W-15/05, 3 positions, female sockets, 10 A rated, 250 VAC, unfiltered commercial, panel mount snap-in, solder eyelet termination, bulk packaging.
| Parameter | Value |
|---|---|
| Series | 716W |
| Filter type | Unfiltered - Commercial |
| Mounting | Panel Mount, Snap-In |
| Connector type | IEC 320-2-2/F |
| Voltage rating - appliance inlet | 250VAC |
| Current rating - appliance inlet | 10A |
| Panel cutout | Rectangular - 32.60mm x 25.30mm |
| Approval agency | CCC, CSA, TUV, UL |
| Package | Bulk |
| Termination | Solder Eyelet |
| Panel thickness | 0.059\" (1.50mm) |
| Accomodates a fuse | No |
| Positions | 3 |
The 716W-15/05 is a 3-position IEC 320-2-2/F receptacle from Qualtek's 716W series, designed for panel-mount snap-in installation with solder eyelet termination. Rated 10 A at 250 VAC, the unfiltered commercial inlet accepts a rectangular panel cutout of 32.60 mm x 25.30 mm and accommodates panel thickness up to 0.059" (1.50 mm).
The panel cutout is rectangular, measuring 32.60 mm x 25.30 mm. The connector mounts via snap-in and accepts panel thickness up to 0.059" (1.50 mm).
