Qualtek 762 series power entry module, order code 762-18/002, IEC 320-C14 receptacle, 3 positions, unfiltered commercial, panel mount snap-in, quick connect 0.250" (6.3mm) termination, includes switch on-off and fuse holder.
| Parameter | Value |
|---|---|
| Series | 762 |
| Filter type | Unfiltered - Commercial |
| Mounting | Panel Mount, Snap-In |
| Connector type | IEC 320-C14 |
| Panel cutout | Rectangular - 66.04mm x 27.00mm |
| Approval agency | CSA, SEMKO, UL |
| Package | Bulk |
| Termination | Quick Connect - 0.250\" (6.3mm) |
| Panel thickness | 0.040\" ~ 0.070\" (1.02mm ~ 1.78mm) |
| Switch features | Switch On-Off |
| Accomodates a fuse | Yes (Fuse Not Included) |
| Fuse holder, drawer | Fuse Holder |
| Positions | 3 |
The 762-18/002 is a 3-position IEC 320-C14 power entry module from Qualtek's 762 series, combining a male-blade receptacle, a switch on-off, and a fuse holder in a single panel-mount snap-in unit. Termination is quick connect 0.250" (6.3mm) tabs; the module accepts panel thickness from 0.040" to 0.070" (1.02 mm to 1.78 mm) and requires a rectangular cutout 66.04 mm x 27.00 mm.
The module is ROHS3 compliant and carries CSA, SEMKO, and UL agency approvals.
The required panel cutout is rectangular, 66.04 mm x 27.00 mm, and the module snaps into panels between 0.040" and 0.070" (1.02 mm to 1.78 mm) thick.
