Qualtek 771W series IEC 320-C8 receptacle, order code 771W-X2/01, 2 positions, non-polarized, 2.5 A at 250 VAC, solder tab termination, panel mount snap-in, unfiltered commercial grade.
| Parameter | Value |
|---|---|
| Series | 771W |
| Filter type | Unfiltered - Commercial |
| Mounting | Panel Mount, Snap-In |
| Connector type | IEC 320-C8, Non-Polarized |
| Voltage rating - appliance inlet | 250VAC |
| Current rating - appliance inlet | 2.5A |
| Panel cutout | Rectangular - 24.50mm x 12.50mm |
| Approval agency | CCC, CSA, UL, VDE |
| Package | Bulk |
| Termination | Solder Tabs |
| Panel thickness | 0.024\" ~ 0.059\" (0.60mm ~ 1.50mm) |
| Accomodates a fuse | No |
| Positions | 2 |
The 771W-X2/01 is the 2-position IEC 320-C8 non-polarized receptacle in Qualtek's 771W series, rated 2.5 A at 250 VAC. Termination is via solder tabs; the housing snaps into a panel cutout of 24.50 mm x 12.50 mm, accepting panel thickness from 0.60 mm to 1.50 mm.
The 771W-X2/01 is ROHS3 compliant and holds approvals from CCC, CSA, UL, and VDE.
