Samtec APA series adapter plug, order code APA-628-G-A1, 28 positions (2 x 14), 0.100" (2.54 mm) pitch, gold-plated mating contacts, through-hole solder termination, open-frame PBT housing.
| Parameter | Value |
|---|---|
| Series | APA |
| Mounting | Through Hole |
| Housing material | Polybutylene Terephthalate (PBT), Glass Filled |
| Contact material - post | Phosphor Bronze |
| Contact material - mating | Phosphor Bronze |
| Material flammability rating | UL94 V-0 |
| Package | Bulk |
| Features | Open Frame |
| Termination | Solder |
| Pitch - post | 0.100\" (2.54mm) |
| Pitch | 0.100\" (2.54mm) |
| Contact finish - post | Gold |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 20.0µin (0.51µm) |
| Contact finish thickness - mating | 20.0µin (0.51µm) |
| Number of positions or pins | 28 (2 x 14) |
The APA-628-G-A1 is the 28-position member of Samtec's APA series of open-frame adapter plugs for DIP-style IC sockets. Gold-plated mating and post contacts (20.0µin / 0.51µm) on phosphor bronze base, through-hole solder termination, and a UL94 V-0 glass-filled PBT housing.
