Samtec ICA series DIP socket, order code ICA-318-STT, 18 positions (2 x 9), 0.100" (2.54mm) pitch, 0.3" (7.62mm) row spacing, tin-plated mating contacts, through-hole solder termination, open frame.
| Parameter | Value |
|---|---|
| Type | DIP, 0.3\" (7.62mm) Row Spacing |
| Series | ICA |
| Mounting | Through Hole |
| Current rating | 1 A |
| Operating temperature | -55°C ~ 105°C |
| Housing material | Polyester, Glass Filled |
| Contact material - post | Brass |
| Contact material - mating | Beryllium Copper |
| Material flammability rating | UL94 V-0 |
| Package | Tube |
| Features | Open Frame |
| Termination | Solder |
| Parameter | Value |
|---|---|
| Pitch - post | 0.100\" (2.54mm) |
| Pitch | 0.100\" (2.54mm) |
| Contact resistance | 10mOhm |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Termination post length | 0.125\" (3.18mm) |
| Number of positions or pins | 18 (2 x 9) |
The ICA-318-STT is an 18-position DIP socket from Samtec's ICA series, arranged in a 2 x 9 grid on 0.3" (7.62mm) row spacing.
Contact resistance is 10 mOhm typical; the brass post is tin-plated for solderability.
Yes, the ICA-318-STT is RoHS3 compliant.
