Samtec Inc. IP5-04-05.0-L-S-1-L-TR — RF Cable Assemblies

Samtec IP5-04-05.0-L-S-1-L-TR, 4-Port 50 Ohm SMT Plug

MPNIP5-04-05.0-L-S-1-L-TR
Active

Samtec ISORATE IP5 series, Plug Female Socket, 4 ports, 50 Ohm, 9.5 GHz max, SMT, Gold center contact, Tape & Reel.

$12.0291Ref. price · indicative, final on quote
Samtec Inc. IP5-04-05.0-L-S-1-L-TR datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

IP5-04-05.0-L-S-1-L-TR specifications
ParameterValue
SeriesISORATE® IP5
MountingSurface Mount
Connector typePlug, Female Socket
Voltage rating200 V
Frequency - max9.5 GHz
Operating temperature-55°C ~ 125°C
Housing colorBlack
Dielectric materialLiquid Crystal Polymer (LCP)
Center contact materialCopper Alloy
PackageTape & Reel (TR) Cut Tape (CT)
Impedance50 Ohms
Insertion loss3dB
Number of ports4
Contact terminationSolder
Center contact platingGold

Product details

The Samtec IP5-04-05.0-L-S-1-L-TR is a 4-port, 50 Ohm RF plug from the ISORATE® IP5 series, built as a surface-mount female socket with gold-plated copper alloy center contacts. It's designed for controlled-impedance signal paths up to 9.5 GHz, with a 3 dB insertion loss ceiling that sets the attenuation budget for the link.

Why the 9.5 GHz Ceiling and 50 Ohm Impedance Matter

The 9.5 GHz max frequency and 50 Ohm impedance define the usable signal band. Gold center contact plating supports operation up to 125°C.

4-Port vs 2-Port and 8-Port Siblings

The IP5-04-05.0-L-S-1-L-TR sits between the 2-port IP5-02-05.0-L-S-1-TR and the 8-port IP5-08-05.0-L-S-1-TR within the same ISORATE IP5 series. Pick the 4-port when your board needs exactly four coaxial signal paths in one connector footprint; the 2-port saves space for a two-line run, and the 8-port consolidates a denser harness without multiplying connector bodies.
