USB 2.0 mini B receptacle — 5 contacts, 1500 mating cycles
The MUSBR-05-S-O-B-SM-A is the 5-contact, single-port USB mini B receptacle in Samtec's MUSBR series, rated for USB 2.0 signaling at 30 V. Gold-plated contacts support 1500 mating cycles, and the operating temperature range spans -50°C to 85°C.
Orange insulation distinguishes the MUSBR-05-S-O-B-SM-A from the black MUSBR-05-F-O-B-SM-A
Within the MUSBR series, the MUSBR-05-S-O-B-SM-A shares the same 5-contact layout, gold plating, and 1500-cycle rating as the MUSBR-05-F-O-B-SM-A; the primary difference is the orange insulation color versus black on the -F- variant.
