Switchcraft Inc. 228
MPN228
Active
CONN PLUG MONO 6.35MM R/A 2COND
$7.93Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Series220
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | 220 |
| Mounting | Free Hanging (In-Line), Right Angle |
| Connector type | Phone Plug |
| Voltage - rated | 500VAC |
| Cable opening | 0.250\" (6.35mm) |
| Body color | Silver, Black |
| Body material | Copper Alloy |
| Contact material | Copper Alloy |
| Housing material | Steel |
| Mating length (Depth) | 1.188\" (30.20mm) |
| Contact material - plating | Tin |
| Gender | Male |
All specifications
| Parameter | Value |
|---|---|
| Package | Bulk |
| Includes | 5 pcs - 1 Connector, 2 pc Handle, 2 Screws |
| Shielding | Shielded |
| Termination | Solder |
| Signal lines | Mono |
| Actual diameter | 0.249\" (6.32mm) |
| Internal switch | Does Not Contain Switch |
| Number of positions (Contacts) | 2 Conductors, 2 Contacts |
| Industry recognized mating diameter | 6.35mm (0.250\", 1/4\") - Headphone |
