Switchcraft Inc. 3501FRX
MPN3501FRX
Active
CONN RCA JACK MONO 3.2MM PNL MT
$3.46Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Panel Mount |
| Connector type | Phono (RCA) Jack |
| Body color | Silver |
| Body material | Brass |
| Contact material | Brass |
| Insulation color | Black |
| Contact material - plating | Nickel |
| Gender | Female |
| Package | Bulk |
| Features | Grounding Tab, Mounting Hardware |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer |
| Shielding | Unshielded |
All specifications
| Parameter | Value |
|---|---|
| Termination | Solder Eyelet(s) |
| Connector size | 3/8\"-32 |
| Signal lines | Mono |
| Panel hole size | 0.375\" (9.52mm) |
| Internal switch | Does Not Contain Switch |
| Number of positions (Contacts) | 2 Conductors, 2 Contacts |
| Industry recognized mating diameter | 3.20mm ID, 9.00mm OD (RCA) |
