Switchcraft Inc. MDSL2ARA
MPNMDSL2ARA
Active
CONN JACK MONO 2.46MM R/A
$4.76Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesMicro-D JAX®
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Micro-D JAX® |
| Mounting | Panel Mount, Through Hole, Right Angle |
| Connector type | Phone Jack |
| Operating temperature | -20°C ~ 65°C |
| Body color | Black |
| Contact material | Copper Alloy |
| Housing material | Plastic |
| Contact material - plating | Nickel |
| Gender | Female |
| Package | Bulk |
| Features | Mounting Hardware, Thread Lock |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer |
All specifications
| Parameter | Value |
|---|---|
| Shielding | Unshielded |
| Termination | Solder Eyelet(s) |
| Connector size | #10-48 |
| Signal lines | Mono |
| Actual diameter | 0.101\" (2.57mm) |
| Internal switch | Single Switch |
| Number of positions (Contacts) | 2 Conductors, 3 Contacts |
| Industry recognized mating diameter | 2.46mm ID (0.097\") |
