Switchcraft Inc. TA3FSH
MPNTA3FSH
Active
CONN PLUG FMALE MINI XLR 3P SLDR
$12.8300Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesTini Q-G® TA
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Tini Q-G® TA |
| Mounting | Free Hanging (In-Line) |
| Connector type | Plug, Female Sockets |
| Fastening type | Latch Lock |
| Voltage rating | 125VAC |
| Current rating | 5A |
| Cable opening | 0.290\" (7.37mm) |
| Operating temperature | -55°C ~ 85°C |
| Color | Silver |
| Shell material | Copper Alloy |
| Insert material | Thermoplastic |
| Contact material | Copper Alloy |
All specifications
| Parameter | Value |
|---|---|
| Primary material | Metal |
| Backshell material, plating | Copper Alloy, Nickel |
| Material flammability rating | UL94 V-0 |
| Package | Bulk |
| Features | Backshell, Cable Clamp, Ground |
| Shielding | Shielded |
| Orientation | Keyed |
| Termination | Solder |
| Applications | Audio, Medical |
| Shell finish | Nickel |
| Positions | 3 |
| Shell size - insert | Mini XLR |
| Contact finish - mating | Silver |
