1-103639-5 TE Connectivity AMPMODU MTE Header, 16 Pos

MPN1-103639-5
Active

TE Connectivity AMPMODU MTE, 16-position, 0.100" (2.54mm) pitch, vertical through-hole header, shrouded 4-wall, latch holder, 3 A per contact, -65°C to 105°C, UL94 V-0, RoHS non-compliant, active production.

$2.5100Ref. price · indicative, final on quote
RoHSRoHS non-compliant
SeriesAMPMODU MTE
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

1-103639-5 key specifications
ParameterValue
SeriesAMPMODU MTE
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLatch Holder
Current rating3A
Operating temperature-65°C ~ 105°C
Contact materialBrass
Insulation colorBlack
Insulation height0.535\" (13.60mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0

All specifications

1-103639-5 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTube
FeaturesKeying Slot
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions16
Contact finish - postTin-Lead
Contact length - post0.130\" (3.30mm)
Overall contact length0.545\" (13.84mm)
Contact finish - matingTin-Lead
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

The 1-103639-5: The 4-wall shrouding and latch holder fastening make it suited for board-to-board or cable connections where vibration resistance matters — automotive, medical, telecom, or general-purpose gear.

Keying slot and latch retention

A keying slot in the housing prevents mis-mating with receptacles that lack the matching key — a simple insurance against reversed or wrong connector insertion. The latch holder locks the header to its mating half; once engaged, it resists unseating from cable tug or vibration better than a friction-only fit.

It is RoHS non-compliant due to tin-lead plating — check your assembly's exemption status if you're shipping to RoHS-regulated markets.

Frequently asked questions

Where can I buy 1-103639-5 and what is the lead time?

Submit an RFQ for current pricing and lead time confirmation.

What is the mating connector for 1-103639-5?

Confirm the receptacle's latch feature matches the header's latch holder.
