16-Position Right-Angle Header on 0.100" Pitch
The 1-103673-5: The header is listed for Board to Board or Cable style, meaning it mates with a matching AMPMODU MTE receptacle — either on another PCB or terminated to a cable assembly.
1-103673-5 TE Connectivity AMPMODU MTE Header, 16 Pos
MPN1-103673-5
Active
TE Connectivity AMP Connectors AMPMODU MTE header, 1-103673-5, 16 positions, single row, 0.100" (2.54 mm) pitch, right-angle through-hole, shrouded-4 wall, gold mating finish, 3 A per contact.
$3.6000Ref. price · indicative, final on quote
RoHSRoHS non-compliant
SeriesAMPMODU MTE
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C~105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Features | Board Lock, Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 16 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.130\" (3.30mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
Where can I buy 1-103673-5 and how do I get a price?
1-103673-5 is available through independent distribution. Submit an RFQ for current pricing and lead time — availability is confirmed at quote time. No stock-holding claim is made on this page.
What is the pitch and row count for 1-103673-5?
The pitch is 0.100" (2.54 mm) and it is a single-row header with 16 positions.
