TE Connectivity AMP Connectors AMPMODU MTE, Header, 20 Positions, 0.100" (2.54mm) Pitch, Through Hole, Right Angle, Shrouded, Gold Mating Contacts, Board Lock, Latch Holder, -65°C to 105°C, 3A
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Features | Board Lock, Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.130\" (3.30mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
A latch holder provides a positive locking mechanism for vibration resistance.
A keying slot prevents mismating with incorrect receptacles. The header is rated UL94 V-0 for flammability, making it suitable for equipment inside enclosures that require flame-rated materials.
Packaged in a tube, the header is supplied as a single unit.
No, the 1-103673-9 is RoHS non-compliant because the contact post finish is tin-lead. Check your application's regulatory requirements before ordering.
The pitch is 0.100" (2.54mm), a standard spacing for many PCB layouts and mating receptacles.
