TE Connectivity AMPMODU System 50 header, order code 1-104074-1, 12 positions, single row, 0.050" (1.27 mm) pitch, 30 VAC, gold-plated mating contacts, through hole right angle, solder termination.
| Parameter | Value |
|---|---|
| Series | AMPMODU System 50 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 30VAC |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Features | Board Guide |
| Shrouding | Shrouded - 2 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Circular |
| Rows | 1 |
| Pitch | 0.050\" (1.27mm) |
| Positions | 12 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.100\" (2.54mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.125\" (3.18mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 1-104074-1 is the 12-position member of TE's AMPMODU System 50 header line, configured for board-to-board or cable connections with a through hole right-angle mount.
A 2-wall shroud and latch holder protect the mating interface and provide positive retention against vibration or cable strain. An integral board guide aids alignment during through-hole soldering.
RoHS and REACH compliance documentation is provided by TE Connectivity AMP Connectors for this part.
