TE Connectivity AMP Connectors 1-111623-9 — Panel-Mount & In-Line Circular

TE AMP-Latch 1-111623-9, 14 Pos IDC Receptacle, 2.00mm Pitch

MPN1-111623-9
Active

TE Connectivity AMP-Latch series, 1-111623-9, 14-position IDC receptacle, 2-row, 0.079" (2.00mm) pitch, 28 AWG ribbon cable, gold 30.0µin contacts, free-hanging, black housing.

$6.0500Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 1-111623-9 datasheet (PDF)
RoHSROHS3 Compliant
SeriesAMP-Latch
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1-111623-9 specifications
ParameterValue
SeriesAMP-Latch
Wire typeRibbon Cable
TypeFemale Socket
MountingFree Hanging (In-Line)
Connector typeReceptacle
Wire gauge28 AWG
Cable terminationIDC
ColorBlack
Pitch0.079\" (2.00mm)
PackageBulk
FeaturesFeed Through, Polarizing Key
Row spacing0.079\" (2.00mm)
Contact finishGold
Rows2
Positions14
Contact finish thickness30.0µin (0.76µm)

Product details

AMP-Latch IDC Receptacle for 28 AWG Ribbon Cable

The TE Connectivity AMP-Latch 1-111623-9 is a 14-position, dual-row IDC receptacle designed for mass-termination to 28 AWG ribbon cable. The housing is black, free-hanging (in-line), and includes a polarizing key to prevent mis-mating with the header — a practical safeguard on a harness assembly bench where orientation is easy to flip.

The specified wire gauge is 28 AWG, the standard for 0.079" pitch ribbon cable. The feed-through feature in the housing allows the cable to pass through the connector body, which is useful for daisy-chain or pass-through wiring in a backplane or card-cage harness.

Frequently asked questions

Is 1-111623-9 RoHS compliant?

Yes, 1-111623-9 is ROHS3 Compliant.
