TE Connectivity AMP Connectors 1-1376009-1 — Pin Headers

1-1376009-1 TE Connectivity Dynamic D-2100 Header, 8 Pos

MPN1-1376009-1
Active

TE Connectivity AMP Connectors Dynamic D-2100 series, 1-1376009-1, 8-position right-angle header, 2.50mm pitch, shrouded 4-wall, through-hole solder, gold-plated mating contacts, rated 5A/250VAC, UL94 V-0.

$4.1000Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 1-1376009-1 datasheet (PDF)
RoHSROHS3 Compliant
SeriesDynamic D-2100
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1-1376009-1 key specifications
ParameterValue
SeriesDynamic D-2100
TypeTab
MountingThrough Hole, Right Angle
Connector typeHeader
Fastening typeDetent Lock
Voltage rating250VAC
Current rating5A
Operating temperature-55°C~105°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.579\" (14.70mm)
Insulation materialThermoplastic, Polyester, Glass Filled

All specifications

1-1376009-1 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTube
FeaturesBoard Lock
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsGeneral Purpose, Industrial
Contact shapeRectangular
Rows2
Pitch0.098\" (2.50mm)
Positions8
Contact finish - postTin
Contact length - post0.134\" (3.40mm)
Contact finish - matingGold
Contact finish thickness - mating15.0µin (0.38µm)

Product details

Mating Half and Pinout

The 2-row, 8-position layout follows a standard 2x4 grid; the rectangular tab contacts are keyed by the housing geometry to prevent mis-mating.

Comparison with Tin-Plated Sibling 1-1871673-2

The closest functional alternative is the 1-1871673-2, a 4-position version of the same right-angle, shrouded Dynamic D-2100 header. The key difference: 1-1871673-2 uses tin plating on the mating contact (31.5µin) instead of gold — tin is adequate for low-cycle applications but will wear faster under repeated mating. For an 8-position BOM line, the 1-1376009-1 provides two more circuits per connector than the 4-position sibling, reducing the connector count on a multi-signal harness.

Frequently asked questions

What is the pinout of 1-1376009-1?

The header has 8 positions arranged in 2 rows, all loaded. The rectangular tab contacts follow a standard 2x4 grid. The shrouded 4-wall housing is keyed to prevent mis-mating with the Dynamic D-2100 receptacle.

Can 1-1376009-1 be used for wire-to-board applications?

Yes, the header is rated for board-to-board or cable interconnects. It mates with Dynamic D-2100 receptacle housings that accept crimp terminals for discrete wires.
