TE Connectivity AMP Connectors 1-1546931-0

1-1546931-0 TE Connectivity Buchanan 10 Pos 5.00 mm Header

MPN 1-1546931-0
Active

TE Connectivity AMP Connectors Buchanan series, 1-1546931-0, Header, Male Pins, Unshrouded, 10 positions, 0.197" (5.00mm) pitch, Through Hole, Vertical, Solder termination, 12 A, 300 V, Black, Bulk.

$2.4100 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesBuchanan
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1-1546931-0 key specifications
ParameterValue
TypeHeader, Male Pins, Unshrouded
SeriesBuchanan
MountingThrough Hole
Voltage - UL300 V
Current - UL12 A
ColorBlack
Contact materialBrass
Housing materialPolyamide (PA66), Nylon 6/6
Insulation height0.079\" (2.00mm)
Material flammability ratingUL94 V-0
Pitch0.197\" (5.00mm)
PackageBulk

All specifications

1-1546931-0 additional specifications
ParameterValue
FeaturesSide Stacking
Number of levels1
Termination styleSolder
Header orientationVertical
Contact tail length0.138\" (3.50mm)
Positions10
Positions per level10
Contact mating finishTin

Product details

10-Position 5.00 mm Unshrouded Header for Terminal Block Integration

The 1-1546931-0: It mates with Buchanan screw-clamp or spring-clamp terminal block plugs to create a field-wiring interface on the PCB. Rated 12 A at 300 V, the header suits power distribution in industrial control panels, HVAC equipment, and building automation where the terminal block is the primary field-wiring point. The unshrouded design gives direct access to the pin tips for probing or for side-stacking multiple headers — the side-stacking feature allows ganging headers to create multi-level terminal blocks without separate interconnects.

At 5.00 mm pitch, the header provides clearance for 300 V working voltage. The 12 A per-contact rating is consistent with the Buchanan series' power-handling capability; derate for ambient temperatures above the UL test point per the housing's UL94 V-0 polyamide material limits. Compared to sibling 1-2213934-1 (same series, bulk, active), the 1-1546931-0 shares the same pitch and current rating but differs in position count — verify the BOM position count before substituting.

No official cross-reference; the Buchanan series includes multiple position variants for the same pitch.
