TE Connectivity AMP Connectors 1-1586037-4 — Pin Headers

1-1586037-4 TE Connectivity VAL-U-LOK Header 14 Pos 4.2mm

MPN1-1586037-4
Active

TE Connectivity VAL-U-LOK, 1-1586037-4, dual-row header, 14 circuits, 4.20mm pitch, tin-plated brass contacts rated 9A per circuit at 600VAC, through-hole solder termination, locking ramp, PA66 nylon housing rated UL94 V-2, -40 to 105 °C operating range, ROHS3 compliant.

$1.1400Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 1-1586037-4 datasheet (PDF)
RoHSROHS3 Compliant
SeriesVAL-U-LOK
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1-1586037-4 key specifications
ParameterValue
SeriesVAL-U-LOK
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLocking Ramp
Voltage rating600VAC
Current rating9A
Operating temperature-40°C ~ 105°C
Contact materialBrass Alloy
Insulation colorNatural
Insulation height0.504\" (12.80mm)
Insulation materialPolyamide (PA), Nylon

All specifications

1-1586037-4 additional specifications
ParameterValue
Material flammability ratingUL94 V-2
StyleBoard to Cable/Wire
PackageBulk
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsGeneral Purpose, Industrial, Lighting
Contact shapeSquare
Rows2
Pitch0.165\" (4.20mm)
Positions14
Row spacing - mating0.165\" (4.20mm)
Contact finish - postTin
Contact length - post0.138\" (3.50mm)
Contact finish - matingTin
Contact finish thickness - post80.0µin (2.03µm)
Contact finish thickness - mating80.0µin (2.03µm)

Product details

14-circuit vertical header for power and lighting

1-1586037-4 is a TE Connectivity VAL-U-LOK dual-row header with 14 positions loaded, 4.20mm pitch, and a shrouded 4-wall housing that protects the male pins during handling and mating. Rated 9A per contact at 600VAC, this through-hole solder header handles power distribution in general-purpose industrial and lighting applications.

Pitch, current, and temperature range for the fit

4.20mm pitch and 0.165" row spacing match the VAL-U-LOK receptacle footprint — a standard spacing for wire-to-board power connectors that keeps routing density moderate.

ROHS3 compliant, supplied in bulk packaging.

Frequently asked questions

What is the mating connector for 1-1586037-4?

This header mates with VAL-U-LOK receptacle housings that accept the corresponding crimp terminals. The locking ramp on the header engages with the receptacle latch for a vibration-resistant connection.

What is the current rating of 1-1586037-4?

Each contact is rated 9A at 600VAC.
