1-1586039-4 TE VAL-U-LOK Header 14 Pos 4.2mm

MPN1-1586039-4
Active

TE Connectivity AMP Connectors VAL-U-LOK 1-1586039-4, 14-position dual-row header, 4.20 mm pitch, 9 A per circuit, tin-plated contacts, board-lock feature, locking ramp, shrouded 4-wall, through-hole solder, 600 VAC, -40 to 105 °C, UL94 V-2.

$1.0300Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesVAL-U-LOK
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

1-1586039-4 key specifications
ParameterValue
SeriesVAL-U-LOK
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLocking Ramp
Voltage rating600VAC
Current rating9A
Operating temperature-40°C ~ 105°C
Contact materialBrass Alloy
Insulation colorNatural
Insulation height0.504\" (12.80mm)
Insulation materialPolyamide (PA66), Nylon 6/6

All specifications

1-1586039-4 additional specifications
ParameterValue
Material flammability ratingUL94 V-2
StyleBoard to Cable/Wire
PackageBulk
FeaturesBoard Lock
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsGeneral Purpose, Industrial, Lighting
Contact shapeSquare
Rows2
Pitch0.165\" (4.20mm)
Positions14
Row spacing - mating0.165\" (4.20mm)
Contact finish - postTin
Contact length - post0.138\" (3.50mm)
Contact finish - matingTin
Contact finish thickness - post80.0µin (2.03µm)
Contact finish thickness - mating80.0µin (2.03µm)

Product details

14 positions at 4.20 mm pitch — the BOM-fit anchor

The 9 A per-circuit rating is the practical ceiling for power distribution in a general-purpose, industrial, or lighting assembly. The locking ramp and shrouded 4-wall design prevent accidental disconnection under vibration and protect the pins during handling — a common failure point in unshrouded headers.

Board lock and through-hole solder — mechanical retention

Through-hole termination with tin-plated posts gives a reliable solder joint without the reflow complexity of SMT.

Frequently asked questions

What is the pinout of 1-1586039-4?

The header has 14 positions loaded in two rows with a 4.20 mm pitch. The contact type is male pin with a square shape. For the exact circuit layout, refer to the TE Connectivity product drawing for 1586039.

Is 1-1586039-4 RoHS compliant?

Yes, it is ROHS3 compliant.
