Right-angle header for wire-to-board power distribution
At a 4.20mm pitch and rated 9A per circuit at 600VAC, it handles mid-power distribution in industrial controls, lighting fixtures, and general-purpose equipment.
1-1586043-6 TE VAL-U-LOK 16-Position Right-Angle Header
MPN1-1586043-6
Active
TE Connectivity VAL-U-LOK, 1-1586043-6, Board to Cable/Wire, Header, 16 Positions, 4.20mm Pitch, Right-Angle, Through Hole, Solder, 9A, 600VAC, Tin Contacts, Locking Ramp, Shrouded - 4 Wall, Active
$1.5800Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesVAL-U-LOK
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | VAL-U-LOK |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 600VAC |
| Current rating | 9A |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass Alloy |
| Insulation color | Natural |
| Insulation height | 0.386\" (9.80mm) |
| Insulation material | Polyamide (PA), Nylon |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-2 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Features | Mounting Flange |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial, Lighting |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.165\" (4.20mm) |
| Positions | 16 |
| Row spacing - mating | 0.165\" (4.20mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.142\" (3.60mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 80.0µin (2.03µm) |
| Contact finish thickness - mating | 80.0µin (2.03µm) |
Product details
Frequently asked questions
What is the mating connector for 1-1586043-6?
The 1-1586043-6 mates with a VAL-U-LOK receptacle housing (e.g., 1-1586042-6 series) that accepts crimp terminals. The locking ramp on the header engages the latch on the receptacle for vibration-resistant mating.
