Faston 0.250" QC receptacle for 10-11 AWG
The 1-160301-9 is a non-insulated female quick-disconnect receptacle in the TE Faston series, accepting 10-11 AWG wire with a 0.250" (6.35mm) tab width. Tin-plated phosphor bronze contact material and a crimp termination suit power-distribution and heavy-gauge wiring applications where a free-hanging, in-line connection is required.
Same-series peer at 15-18 AWG
Within the Utilux series, the 1-1627194-4 shares the same 0.250" (6.35mm) tab width and 0.032" (0.81mm) tab thickness but accepts 15-18 AWG wire with a brass contact — the 1-160301-9 handles heavier 10-11 AWG with phosphor bronze.
Crimp termination and insulation range
Crimp termination accepts wire insulation diameters from 0.150" to 0.201" (3.81mm to 5.10mm) for 10-11 AWG stranded or solid conductors.
