TE Connectivity AMP Connectors 1-1734742-6 — FFC / FPC Cable Assemblies

1-1734742-6 TE Connectivity FFC FPC Connector 16 Position

MPN1-1734742-6
Active

TE Connectivity AMP Connectors 1-1734742-6, FFC/FPC connector, 16 positions, 0.50 mm pitch, vertical SMD, ZIF slide lock, gold flash contacts, 0.5 A, 50 V, UL94 V-0, Tape & Reel.

$0.6309Ref. price · indicative, final on quote
RoHSRoHS Compliant
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1-1734742-6 key specifications
ParameterValue
MountingSurface Mount
Cable end typeStraight or Tapered
Flat flex typeFFC, FPC
Connector (Contact type)Contacts, Vertical - 1 Sided
Voltage rating50V
Current rating0.5A
Operating temperature-20°C ~ 85°C
Housing colorBlack
Actuator colorBrown
Contact materialPhosphor Bronze
Housing materialThermoplastic, Glass Filled
Actuator materialThermoplastic

All specifications

1-1734742-6 additional specifications
ParameterValue
Height above board0.163\" (4.15mm)
Material flammability ratingUL94 V-0
Pitch0.020\" (0.50mm)
PackageTape & Reel (TR) Cut Tape (CT)
FeaturesSolder Retention, Zero Insertion Force (ZIF)
TerminationSolder
Contact finishGold
Locking featureSlide Lock
FFC, FCB thickness0.30mm
Positions16
Contact finish thicknessFlash

Product details

16-position 0.50 mm pitch vertical FFC/FPC connector with ZIF slide lock

The 1-1734742-6 is a 16-position, 0.50 mm pitch FFC/FPC connector from TE Connectivity's 1734742 series, designed for vertical surface-mount termination with a ZIF (zero insertion force) slide lock actuator. It accepts FFC or FPC cables 0.30 mm thick with straight or tapered ends, and the gold flash on phosphor bronze contacts provides corrosion resistance for signal-level interconnects rated at 0.5 A per contact and 50 V. The housing is black thermoplastic, glass filled, rated UL94 V-0, with a brown actuator; the connector stands 4.15 mm above the board and operates from -20°C to 85°C.

Frequently asked questions

Is 1-1734742-6 a ZIF connector?

Yes, it features a zero insertion force (ZIF) slide lock actuator, which reduces wear on FPC pads during repeated mating cycles.

What is the pitch of 1-1734742-6?

The pitch is 0.020" (0.50 mm), which is the primary routing constraint for the PCB footprint.

Does 1-1734742-6 have a slide lock?

Yes, the locking feature is a slide lock, which holds the FFC/FPC in place without a secondary latch.
