TE Connectivity AMP Connectors High Performance Interconnect (HPI) series, 1-1775469-4, a 14-position, single-row, 2.00mm pitch, surface-mount right-angle pin header with full 4-wall shrouding and solder retention features.
| Parameter | Value |
|---|---|
| Series | High Performance Interconnect (HPI) |
| Type | Male Pin |
| Mounting | Surface Mount, Right Angle |
| Connector type | Header |
| Voltage rating | 250V |
| Current rating | 3A |
| Operating temperature | -25°C ~ 85°C |
| Contact material | Brass |
| Insulation color | Natural |
| Insulation height | 0.217\" (5.51mm) |
| Insulation material | Polyamide (PA9T), Nylon 9T |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial, Medical |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 14 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.139\" (3.53mm) |
| Contact finish thickness - post | 80.0µin (2.03µm) |
| Contact finish thickness - mating | 80.0µin (2.03µm) |
The 1-1775469-4: The right-angle orientation routes the mating cable parallel to the board, saving vertical clearance in enclosures where a vertical header would not fit. The shrouded 4-wall housing protects the square male pins during blind-mate cable assembly and prevents misalignment.
1-1775469-4 is an active TE Connectivity part. We source it per RFQ against your BOM quantity. Submit a request for current pricing and lead time; availability is confirmed at quote time.
It is a single-row, 14-position header with a 2.00mm pitch. All positions are loaded. The mating pin length is 0.139 inches (3.53mm).
