Right-angle 3.81mm pitch header for industrial board-to-board or cable duty
The 1-178295-2 is a 5-position, single-row header from TE's Dynamic D-3100 series, on a 3.81mm pitch. It's a through-hole, right-angle part with a shrouded four-wall housing and a detent lock that keeps the mating half seated under vibration.
Gold mating, tin post, and a board lock that holds
The solder tails are tin, which mates well with standard HASL or ENIG pads. The housing is black thermoplastic, polyester, glass-filled, rated UL94 V-0.
