Active Sourcing and Lifecycle
No stock-holding claim — each order is sourced from the supply base.
Single-row header with 8 positions on 0.150" (3.81mm) pitch — the board footprint is defined by the 3.81mm centerline spacing. The 8-position count matches the BOM line for a 8-circuit interconnect. The 0.150" post length sets the minimum board thickness and solder fillet geometry.
Contact Plating and Mating Interface
Board Lock and Mechanical Retention
In a vibration-prone application, the board lock prevents the header from lifting off the board during mate/unmate cycles. The insulation height of 0.850" (21.59mm) provides clearance for the mating receptacle.
Material, Temperature, and Compliance
Voltage rating is 250V. The connector is ROHS3 Compliant per the manufacturer's declaration.
