TE Connectivity AMP Connectors 1-188275-4 — Female Socket Headers

1-188275-4 TE Connectivity Micro-MaTch 14-Pin Receptacle

MPN1-188275-4
Active

TE Connectivity AMP Connectors, Micro-MaTch series, 1-188275-4, 14-position dual-row receptacle, 0.100" (2.54mm) pitch and row spacing, tin-plated forked contacts, surface-mount termination, UL94 V-0 rated housing, active production.

$2.6400Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesMicro-MaTch
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1-188275-4 key specifications
ParameterValue
SeriesMicro-MaTch
TypeForked
MountingSurface Mount
Connector typeReceptacle
Fastening typePush-Pull
Voltage rating100VDC
Operating temperature-40°C ~ 105°C
Contact materialPhosphor Bronze
Insulation colorRed
Insulation height0.209\" (5.30mm)
Insulation materialPolyamide (PA46), Nylon 4/6, Glass Filled
Material flammability ratingUL94 V-0

All specifications

1-188275-4 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTape & Reel (TR) Cut Tape (CT)
TerminationSolder
ApplicationsAutomotive, General Purpose
Rows2
Pitch0.100\" (2.54mm)
Positions14
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact finish - matingTin

Product details

14-Position Dual-Row SMT Receptacle for Board-to-Board or Cable

It uses a 0.100" (2.54mm) pitch and row spacing, making it footprint-compatible with standard 0.100" dual-row headers.

Surface-Mount Termination and Housing Details

Termination is solder-only via surface-mount pads, with the part supplied in Tape & Reel (TR) and Cut Tape (CT) packaging for pick-and-place assembly. The red polyamide (PA46) glass-filled housing carries a UL94 V-0 flammability rating and an insulation height of 0.209" (5.30mm).

Frequently asked questions

Where can I buy 1-188275-4?

1-188275-4 is quoted to order against your BOM quantity. Availability and current pricing are confirmed at quote time — submit an RFQ for the exact quantity and delivery need.

What is the mating connector for 1-188275-4?

This receptacle mates with a standard 0.100" (2.54mm) pitch, dual-row pin header. The Micro-MaTch series offers matching headers — confirm the specific header order code against your application's pin length and plating requirements.
