TE Connectivity AMP Connectors 1-1971875-3 — Connector Housings

1-1971875-3 TE Power Triple Lock 9-Pin Receptacle Housing

MPN1-1971875-3
Active

TE Power Triple Lock, High Temp receptacle housing, 1-1971875-3, 9 positions, 3 rows, 0.236" (6.00mm) pitch, 0.319" (8.10mm) row spacing, panel mount snap-in, latch lock, natural PBT, crimp termination, contacts not included.

$0.8200Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesPower Triple Lock, High Temp
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1-1971875-3 specifications
ParameterValue
SeriesPower Triple Lock, High Temp
TypeTab
MountingPanel Mount, Snap-In
Connector typeReceptacle
Fastening typeLatch Lock
Operating temperature-55°C ~ 105°C
ColorNatural
Insulation materialPolybutylene Terephthalate (PBT)
NoteContacts Not Included
Pitch0.236\" (6.00mm)
PackageBulk
Row spacing0.319\" (8.10mm)
Rows3
Contact terminationCrimp
Positions9

Product details

Power Triple Lock 9-Way Receptacle Housing

The TE 1-1971875-3 is a 9-position receptacle housing from the Power Triple Lock, High Temp series, built for wire-to-wire or wire-to-panel power interconnects where a secure, vibration-resistant mate is needed. The 6.00 mm pitch and three rows give it the terminal spacing to handle moderate power circuits without crowding the wire bundle. This is a bare housing — contacts are ordered separately and crimped into the wire before insertion. Panel-mount snap-in ears let you fix the housing to a cutout, turning the connector into a bulkhead pass-through.

Frequently asked questions

Does 1-1971875-3 include contacts?

No — the listing explicitly notes contacts are not included. You need to order the matching Power Triple Lock crimp terminals separately.

What is the mating plug for 1-1971875-3?

This is the receptacle half. It mates with the corresponding Power Triple Lock plug housing of the same series and position count. The latch lock on the receptacle engages the plug's locking ramp.
