What This Backshell Does in a CPC Assembly
The TE Connectivity 1-206062-7 is a backshell with integrated cable clamp for the CPC (Circular Plastic Connector) series, shell size 11. It provides strain relief and cable retention at the rear of a mated CPC connector pair, with a 180° straight cable exit that keeps the cable aligned with the connector axis.
Thread Fit and Cable Opening — What Fits
The 5/8-24 UNEF thread mates directly onto the rear of a CPC shell size 11 connector. The cable opening measures 0.329" (8.36 mm) in diameter, which dictates the maximum cable jacket size that passes through the clamp. For a harness builder, this means the backshell accepts a cable bundle or single-jacket cable up to that diameter; anything larger requires a different shell size or a different backshell variant.
What Ships in the Box
The package includes four pieces: two cable clamp halves and two screws. The clamp screws are the hardware that cinches the clamp around the cable jacket after the backshell is threaded onto the connector. No separate hardware order is needed for a single assembly.
