Board-to-Board Stacking with 2.00mm Pitch
The 1-2314844-0: This AMPMODU receptacle is a 10-position, dual-row board-to-board connector on a 2.00mm pitch — the footprint and row spacing are both 2.00mm, which sets the board routing density and the mated stack height with a matching header. Rated 2A per contact at 125VAC, it's a signal-level interconnect — the current ceiling is well within the housing's thermal budget for logic and low-power I/O. The gold mating finish (3.94µin thick) on phosphor bronze contacts provides corrosion resistance for moderate mating cycles; the tin-plated solder tails (12.0µin) are standard for SMT reflow.
Surface-mount termination with pick-and-place features means this receptacle is designed for automated assembly — the tube packaging feeds into standard SMT placement equipment without extra handling.
This is a receptacle with push-pull fastening, accepting a square-pin header of the same 2.00mm pitch and dual-row layout — the bottom or top entry design allows stacking flexibility. All 10 positions are loaded; the black LCP housing and gold mating finish are the key identifiers for matching the correct header half.
