11-Position Right-Angle Header for Terminal Block Systems
The 1-2350513-1 is an 11-position, single-level, right-angle header from the TE Connectivity TB Buchanan series. It is designed to mate with the corresponding Buchanan plug or socket to form a wire-to-board connection for industrial terminal block applications.
Through-hole mounting with solder termination provides a reliable mechanical and electrical connection to the PCB. The contact tail length is 0.177" (4.50 mm), which sets the board thickness range for proper solder joint formation. The insulation height of 0.327" (8.30 mm) and the right-angle orientation together define the clearance above the PCB for the mated connector assembly.
Material and Environmental Ratings
The green color is a visual identifier for the TB Buchanan series, helping distinguish it from other header families on the same board.
Sourcing and Compliance — Active Production
It is RoHS compliant per the current directive. No stock-holding claim — quoted to order per RFQ.
