TE Connectivity AMP Connectors 1-2834011-5

TE Connectivity 1-2834011-5 Terminal Block, 5 Pos, 3.5mm, 6A

MPN 1-2834011-5
Active

TE Connectivity, 1-2834011-5, 5 Position, 3.50mm Pitch, 6 A, 300 V, Through Hole, Push-In Spring, Green

$0.9900 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1-2834011-5 specifications
ParameterValue
MountingThrough Hole, Kinked Pin
Voltage300 V
Current6 A
Wire gauge14-20 AWG
Wire terminationScrewless - Leg Spring, Push-In Spring
Operating temperature-40°C ~ 105°C
ColorGreen
Housing materialPolyamide (PA66), Nylon 6/6
Contact material - platingCopper Alloy - Tin Plated
Pitch0.138\" (3.50mm)
PackageBulk
Number of levels1
Mating orientationVertical with Board
Positions per level5

Product details

It uses a screwless push-in spring clamp — the leg spring mechanism grabs the stripped wire when you push it into the entry, no screwdriver needed for the wire termination itself.

What the 6 A and 300 V Ratings Mean for Your Circuit

The 6 A per-position current rating and 300 V voltage rating define the electrical envelope for this block.

Wire Termination: Push-In Spring for 14-20 AWG

The 1-2834011-5 accepts 14-20 AWG wire. The push-in spring mechanism — officially a screwless leg spring — lets you terminate solid or ferruled stranded wire by simply pushing it into the clamp opening. No screw turning, no torque spec to hit. For stranded wire without a ferrule, the spring may not grip as reliably; a ferrule is recommended for stranded conductors in this style of clamp. The through-hole, kinked-pin mounting holds the block to the board during wave solder, and the vertical orientation means wires enter from the top, perpendicular to the PCB.

MPN
1-2834011-5
