TE Connectivity AMP Connectors 1-284513-0 — Header Plugs & Sockets

1-284513-0 TE Connectivity 10-Position 3.81mm Right-Angle

MPN1-284513-0
Active

TE Connectivity AMP Connectors Buchanan series, 1-284513-0, Header, Male Pins, Shrouded (4 Side), 10 positions, 0.150" (3.81mm) pitch, 90° right-angle through-hole, tin contact finish, 11 A, 300 V, UL94 V-0.

$3.7000Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesBuchanan
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1-284513-0 key specifications
ParameterValue
TypeHeader, Male Pins, Shrouded (4 Side)
SeriesBuchanan
MountingThrough Hole
Voltage - UL300 V
Current - UL11 A
Operating temperature-40°C ~ 110°C
ColorGreen
Contact materialPhosphor Bronze
Housing materialPolyamide (PA66), Nylon 6/6
Insulation height0.287\" (7.30mm)
Material flammability ratingUL94 V-0
Pitch0.150\" (3.81mm)

All specifications

1-284513-0 additional specifications
ParameterValue
PackageBulk
Number of levels1
Termination styleSolder
Header orientation90°, Right Angle
Contact tail length0.134\" (3.40mm)
Positions10
Positions per level10
Contact mating finishTin

Product details

10-position 3.81mm right-angle header for terminal block systems

1-284513-0 is a 10-position, single-level header from the TE Buchanan series, designed for 0.150" (3.81mm) pitch terminal block applications. Rated at 11 A per circuit at 300 V, this header suits power distribution in industrial control panels and building automation equipment. Tin contact mating finish suits applications where cost per position is prioritized over high-cycle durability.

Through-hole termination and PCB footprint

Termination is solder via through-hole, with a contact tail length of 0.134" (3.40mm). Operating temperature range is -40°C to 110°C.

Sourced per RFQ against BOM quantities.

Frequently asked questions

Is 1-284513-0 RoHS compliant?

Yes, it is ROHS3 compliant.

What is the pitch of 1-284513-0?

The pitch is 0.150" (3.81mm).
