12-position shrouded header for terminal block systems
Rated 11 A at 300 V per UL, the header suits control cabinet wiring, PLC I/O modules, and industrial power distribution where the 3.50mm pitch balances density with tool-free wire entry on the mating plug side.
Right-angle orientation and board fit
The 0.285" (7.25mm) insulation height leaves room for component clearance under the header body. Contact tail length is 0.134" (3.40mm), typical for 1.6mm thick PCBs with through-hole solder termination. The mating flange feature provides a keyed alignment with the plug's locking mechanism, reducing the risk of partial insertion under vibration.
